MULTIMETER DIGITAL LCR WITH DIODE TRANSISTOR
Part No: UT603
Manufacturer: UNI-TREND TECHNOLOGY LTD.
Stock No: MJJR-811
SKU No: 238232
.jpg)
(1).jpg)
(2).jpg)
(3).jpg)
(4).jpg)
Image is for illustrative purposes only. Please refer to product description.
$59.95 CAD
Stock may not be available at all store locations. Inventory quantites can change without notice.
| Burlington | 2 | |
| Cambridge | 2 | |
| Markham | 1 | |
| Mississauga | 2 | |
| Scarborough | 3 | |
| Vaughan | 3 | |
| Warehouse | 8 |
| Specifications | Range | Best Accuracy |
| Model | UT603 | |
| Resistance (Ω) | 200Ω/2KΩ/20KΩ/200KΩ/2MΩ/20MΩ | ±(0.8%+1) |
| Capacitance (C) | 2nF/20nF/200nF/2uF/20uF/200uF/600uF | ±(1%+5) |
| Inductance (H) | 2mH/20mH/200mH/2H/20H | ±(2%+8) |
| Features | ||
| Display Count | 1999 | |
| Manual Range | √ | |
| Diode | √ | |
| Transistor | √ | |
| Continuity Buzzer | √ | |
| Low Battery Indication | √ | |
| General Characteristic | ||
| Power | 9V Battery（6F22) | |
| LCD Size | 61mm X 32 mm | |
| Product Color | Red and Grey | |
| Product Net Weight | 312g | |
| Product Size | 172mm X 83mm X38 mm | |
| Standard Accessories | Battery, Test Clip,Holster | |
| Standard Individual Packing | Gift Box, English Manual | |
| Standard Quantity Per Carton | 40 PCs | |
| Standard Carton Measurement | 598mm X 418mm X 340mm (0.085 CBM Per Standard Carton) | |
| Standard Carton Gross Weight | 21Kg | |
Product Manual (en)
