15 open collector contacts: max. 50V/50mA
LED indication for each output
Multiple IR sensors possible (type : IR38DM)
Transmitter - receiver range: up to 20m
4 different modes:
15 independent outputs
15 rotary outputs
7 independent outputs & 8 rotary outputs
7 rotary outputs & 8 rotary outputs (independent from each other)
3 addresses allow the use of multiple receivers in one room
Power supply: 8 ~ 14VDC or 2x6 ~ 2x12VAC (150mA)
Current consumption:
All outputs off: 10mA
All output on: 150mA
Dimensions: 2.8" x 4.5"
*Prices subject to change without notice. We reserve the right to limit quantities.
-
Age
12+
-
Part No
K8050
-
Manufacturer
Velleman
-
Stock No
2031-SE3
-
SKU No
204608
Limited Stock Available To purchase, Please contact our Sales Department
(+1-416-494-8999) or email shop@sayal.com
