Sperry DSA2009 Specifications:
� Display: 3.5 digit LCD max reading 4000 with function and decimal annunciators
� Range Selection: Manual rotary switch
� Overrange Indication: 3 least significant digits blanked
� Sampling Rate: 3 times per second
� Dielectric Strength: 2500VAC for one minute
� Max Conductor Size: 2.16" (55mm) diameter
� Battery Indicator: "BATT" symbol appears on display to indicate low battery
� Operating Environment: 0� to 40� C (14� to 122� F) at <85% RH
� Storage Environment: -20� to 60� C (-4� to 140� F) at <90% RH
� Power Supply: (1) 9V Transistor type battery (B-4)
Sperry DSA2009 Features:
� Meets CE Requirements
� Lifetime Limited Manufacturer Warranty
� Designed to CAT III 600V; CAT II 1000V
� Pollution Degree 2 IEC 61010-1
� Current Capability up to 2000A
� Thumbwheel Power/Range Selector Switch
� Tear Drop Shaped Jaws
� Electronic Overload Protection
� Enhanced True RMS Measurement Capability
� Data Hold
� Peak Hold
� Continuity
� Sleep Function
� Output Terminal
� Broad Frequency Response (40Hz - 1KHz)
� Note: Instrument is designed to take current readings on circuits with a maximum of 600V AC.
