Sensor 1/3" SONY 960H SUPER HAD CCD Total Pixels NTSC=811(H)x508(V) / PAL=795(H)x595(V) Effective Pixels NTSC=768(H)x494(V) / PAL=752(H)x582(V) Scanning System 2:1 Interlace Synchronization Internal O.S.D. Built-in S/N Ratio More than 52dB Gamma Characteristic r=0.45 Resolution 700 TV Lines Min. Illumination CDS OFF 0.1 Lux / CDS ON 0.0002 Lux Lens 4mm Fixed Board Lens (8/12mm)-Option White Balance ATW/AWB/FIXED/MANUAL Electronic Shutter Speed NTSC=Auto/Manual(1/60sec~1/120,000sec) / PAL=Auto/Manual(1/50sec~1/120,000sec) Video Output CVBS : 1.0Vp-p 75ohm BLC On / Off AGC On / Off Day&Night(Color / B/W) Color / Auto / B/W Display Adjust Contrast / Sharpness / CB-Gain / CR-Gain Privacy On / Off (4 Programmable Zone) Power Supply DC 12V Power Consumption CDS ON:350mA Max Operating Temp./Humid -35°C ~ +50°C / -31°F ~ +122F, RH 95% Max. Dimension 63(W) x 58(H) x 130(D) Weight 800g

---
