RELAY DC 5V 1P1T 10A 4P PCMT 10A/250VAC 5A/32VDC
Part No: G5Q-1A-DC5V
Manufacturer: OMRON ELECTRONIC COMPONENTS
Stock No: JCFA-3603
SKU No: 243064
Stock Number: JCFA-3603    $4.00
RELAY DC 5V 5887

Image is for illustrative purposes only. Please refer to product description.

$4.00 CAD
** International Order Shipping Charges Apply - Read about it here.
Stock may not be available at all store locations. Inventory quantites can change without notice.
Burlington7
Cambridge3
Markham8
Mississauga3
Scarborough9
Vaughan3
Warehouse 84
Details
A Miniature Power Relay with
1-pole 10A Switching Capacity
• Excellent switching performance for a variety of loads.
• Small, yet provides 8-kV impulse withstand voltage (between coil
and contacts).
• Low coil power consumption (SPST-NO: 200 mW)
• Coil insulation system: Class F (UL1446).
• IEC/EN 60335-1 conformed. (-HA Model)
• Reduced power consumption with voltage holding and pulse width

FITS ON BREADBOARD
